Application Field And Product Advantages
Dispersion Oxygen Generator
Dispersion oxygen generator means that the oxygen of the oxygen generator can be diffused to the whole area, that is, it can supply oxygen to the whole house so that people in the room don’t need to wear oxygen pipes, and they can walk and sleep freely in the house.
Usage Advantages:
- Health: improve the oxygen concentration of indoor environment, effectively alleviate altitude reaction, improve sleep quality and eliminate fatigue.
- Comfort: no need to wear a variety of breathing masks or breathing mouths to relieve the shackles of traditional oxygen inhalation.
- Freshness: absorb harmful gases such as carbon dioxide, carbon monoxide and hydrogen sulfide in the air to purify the air.
- Energy-saving: low oxygen consumption cost.
- Voiceless: it can also ensure that you have a quiet atmosphere when the equipment is running.
Product Specification
| Oxygen flow: | 10L~30L/min |
| Oxygen concentration: | 90%±3% |
| Oxygen pressure: | 0.04~0.07Mpa |
| Purify: | CADR ≤ 450m³/h |
| Power supply: | AC220V/50Hz |
| Rated power: | ≤50W |
| Noise: | ≤45dB(A) |
| Product Size(L*W*H) : | Φ37*123.5 cm |
| N.W (Kg) | 16.5 kgs |
| Applicable area : |
10~50㎡ (According to the selected outdoor machine) |
It is recommended to match with more than 40 liters outdoor dispersion machine.
Recommended
Outdoor Dispersion Machine
For this Indoor Oxygen Outlet Terminals, We Recommended to mach more than 40L outdoor dispersion machine. Below outdoor dispersion for you’re chosen.
QJ10L/T-2A
QJ15L/B-2A
QJ20L/T-YH
QJ20L/T-2A
Outdoor Dispersion machine
(Thomas compressor)
Outdoor Dispersion machine
(Thomas compressor)
Outdoor Dispersion machine
(Thomas compressor)
Outdoor Dispersion machine
(Thomas compressor)
Oxygen output/flow: 10L±10% L/min
Oxygen concentration: 90%±3%
Oxygen pressure: 0.03 ~ 0.07MPa
Applicable area: 10~20 ㎡
Noise: ≤58 dBA
Rated power: ≤ 650 w
Material ： Metal Plate
Product Size(L*W*H) : 61.5*34*60 cm
Oxygen output/flow: 15L±10% L/min
Oxygen concentration: 90%±3%
Oxygen pressure: 0.03 ~ 0.07MPa Applicable area：10~25 ㎡ Noise: ≤58 dBA Rated power: ≤ 1000 w
Material ： Metal Plate
Product Size(L*W*H) : 71.5*37*62 cm
Oxygen output/flow: 20L±10% L/min
Oxygen concentration: 90%±3%
Oxygen pressure: 0.03 ~ 0.07MPa
Applicable area：20~30 ㎡
Noise: ≤60 dBA
Rated power: ≤ 1300W
Material ： Metal Plate
Product Size(L*W*H) : 78.2*38*70 cm
Oxygen output/flow: 20L±10% L/min
Oxygen concentration: 90%±3%
Oxygen pressure: 0.03 ~ 0.07MPa
Applicable area : 20~30 ㎡ Noise: ≤60 dBA
Rated power: ≤ 1300W
Material ： Metal Plate
Product Size(L*W*H) : 85*40*70 cm
QJ30L/T-21
QJ40L/T-21
QJ50L/T-21
QJ60L/T-21
Outdoor Dispersion machine
(Thomas compressor)
Outdoor Dispersion machine
(Thomas compressor)
Outdoor Dispersion machine
(Thomas compressor)
Outdoor Dispersion machine
(Thomas compressor)
Oxygen flow: 30±10% L/min
Oxygen concentration: 90%±3%
Oxygen pressure: 0.03~0.07Mpa
Power supply: AC220V/50Hz
Rated power: ≤1830W
Noise: ≤60 dB(A)
Applicable area: 30~45㎡
Compressor option: Made in China or Thomas
Material ： Metal Plate
Product Size(L*W*H) : 83*68*86.5 cm
Oxygen flow: 40±10% L/min
Oxygen concentration: 90%±3%
Oxygen pressure: 0.03~0.07Mpa
Power supply: AC220V/50Hz
Rated power: ≤2450W
Noise: ≤60 dB(A)
Applicable area: 40~60㎡
Compressor option: Made in China or Thomas
Material ： Metal Plate
Product Size(L*W*H) : 95*62*90 cm
Oxygen flow: 50±10% L/min
Oxygen concentration: 90%±3%
Oxygen pressure: 0.03~0.07Mpa
Power supply: AC220V/50Hz
Rated power: ≤3050W
Noise: ≤62 dB(A)
Applicable area: 50~80㎡
Compressor option: Made in China or Thomas
Material ： Metal Plate
Product Size(L*W*H) : 120*68*86 cm
Oxygen flow: 60±10% L/min
Oxygen concentration: 90%±3%
Oxygen pressure: 0.03~0.07Mpa
Power supply: AC220V/50Hz
Rated power: ≤3760W
Noise: ≤65 dB(A)
Applicable area: 60~90㎡
Compressor option: Made in China or Thomas
Material ： Metal Plate
Product Size(L*W*H) : 120*68*86 cm
Application Field Of Dispersion Oxygen Generator
- It is suitable for hypoxia caused by closing windows in the living room, study, and bedroom in winter.
- Insufficient oxygen supply for the elderly and children.
- Fatigue and sleepiness caused by lack of oxygen in office and conference room areas.
- lt is suitable for a gymnasium, sauna room, early education center, kindergarten, nursing home community hospital, and other places with a large flow of oxygen demand.
- lt can be customized according to the room area. Please contact us for details.
Whole House Oxygen Production
Diffuse oxygen supply:
directly improve the oxygen content of the indoorenvironment without wearing an oxygen mask or oxygen tube.Digital multi-connected intelligent control technology: combined with buscentralized control communication technology, it can not only connectmultiple oxygen generator hosts in parallel and start them on demandbut also add or remove oxygen terminals for other rooms at any time, soas to realize the intelligent control of oxygenation in the whole house.
